1/2
Slika slična
Siemens 3SE50000AA61 3SE5000-0AA61 dodatni pokretač Motiv ispisa bez valjak od plemenitog čelika rasterska rupa metalna
Vrsta proizvoda
dodatni pokretač
Određene značajke prekidača/tipkala
rasterska rupa
Izvedba
Poluga 19 mm
Motiv ispisa
bez
Vrsta aktiviranja
valjak od plemenitog čelika
Tehnički list (PDF)
EAN:
Šifra proizvođača:
Kataloški br.:
Broj
Ukupno (38,99 € / komad)
38,99 €
uklj. PDV
Uključena je politika povrata u roku od 14 dana
Tehnički podaci
- Vrsta proizvoda
dodatni pokretač
- Određene značajke prekidača/tipkala
rasterska rupa
- Izvedba
Poluga 19 mm
- Motiv ispisa
bez
- Vrsta aktiviranja
valjak od plemenitog čelika
- Vrsta osvjetljenja
bez
- Boja
metalna
- Dužina
100 mm
- Pogodno za (detalji)
3SE5 poluokretni pogon
- Sadržaj
1 St.
- Tip
3SE5000-0AA61
- RoHS-konforno
Da
Other
None
None
None
None
Roller cam straight
- UKCA
da
Dokumenti i preuzimanja
Podatkovna tablica
Podatkovna tablica 702997 Siemens 3SE50000AA61 3SE5000-0AA61 dodatni pokretač Motiv ispisa bez valjak od plemenitog čelika rasterska rupa metalna
Upute za rad i sigurnost
Upute za rad i sigurnost 702997 Siemens 3SE50000AA61 3SE5000-0AA61 dodatni pokretač Motiv ispisa bez valjak od plemenitog čelika rasterska rupa metalna
Opis
Adjustable-length Twist lever for position switch 3SE51/52 Metal lever 100 mm long Positive fit (grid hole) Stainless steel roller 19 mm actuator for part-turn actuator SIRIUS 3SE5 for position sensing of machine parts and position monitoring of protection equipment.
The modular design of the 3SE5 position switches permits a host of variants with a small number of bearing types. The wide variety of plug-in connectors and rollers meets almost all everyday requirements in industry. LEDs indicate the current state of the device. Thanks to quick-connect technology, the time required for connection can be considerably reduced. Operating points and mounting in accordance with EN 50047 and EN 50041. The devices have worldwide approval (IEC, UL). With the corresponding switch configuration, the highest safety requirements specified by PL e or SIL 3 can be met. The integrated ASIsafe electronics requires a low current input.
Various enclosure sizes, with different contacts, are available in plastic or metal, or compact design. Some versions are optionally available with an LED status display and M12 plug. The 3SF1 series with direct connection to the AS-Interface bus system completes the portfolio.
Depending on the design, actuator heads and plug-in connectors, as well as other mounting/connection accessories, are available.
Safety is a SIRIUS business.
The modular design of the 3SE5 position switches permits a host of variants with a small number of bearing types. The wide variety of plug-in connectors and rollers meets almost all everyday requirements in industry. LEDs indicate the current state of the device. Thanks to quick-connect technology, the time required for connection can be considerably reduced. Operating points and mounting in accordance with EN 50047 and EN 50041. The devices have worldwide approval (IEC, UL). With the corresponding switch configuration, the highest safety requirements specified by PL e or SIL 3 can be met. The integrated ASIsafe electronics requires a low current input.
Various enclosure sizes, with different contacts, are available in plastic or metal, or compact design. Some versions are optionally available with an LED status display and M12 plug. The 3SF1 series with direct connection to the AS-Interface bus system completes the portfolio.
Depending on the design, actuator heads and plug-in connectors, as well as other mounting/connection accessories, are available.
Safety is a SIRIUS business.
Isporuka uključuje
- Siemens 3SE5 3SE5000-0AA61 okretljiva ručica s podesivom dužinom, Rotary pogon, metalna ručka
Napomene
Montaža samo s odgovarajućim zakretnim pogonom Narudžba br. 70 30 19 moguće.
